Map Showing Property of the Hoboken R.R. Warehouse & Steamship Connecting Co. Hoboken, N.J., Sept., 1906
Archive
Map Showing Property of the Hoboken Railroad Warehouse and Steamship Connecting Co. Hoboken, N.J., September, 1906
Survey datum
Gas and water lines, sewer lines
5th to 11th Streets; Hudson River to Hudson St.
The Railroad company was the predecessor to the Hoboken Manufacturers Railroad which later became the Hoboken Shore Railroad.
Title block, front lower right corner:
Map Showing Property of the
Hoboken Railroad Warehouse and Steamship Connecting Co.
Hoboken, N.J.
September, 1906
Scale: 1 inch = 40 feet W.F. Whittemore, C.E.
Note: location of pipelines are approximate determined by surface indications
Title from back - upper left corner
#2049
Shoring Encroachments
Along line of Hoboken S
Shore Road 1906[?]
2049 [underlined]
Pipe Lines In
River Road
+
Around the Terminal
Buildings
----
Drawing on linen-backed paper, (sepia line print), 38" high x 75" wide. PDF on file of sectional scans only (6 across x 5 down); tiffs media archives.
-----
Some named buildings are drawn and colored.
2012.040.0003
2012.040
Purchase
Purchase
Museum Purchase.
1906 - 1906
Date(s) Created: 1906 Date(s): 1906
Status: OK Status By: dw Status Date: 2012-09-19
